Industrial arm / Cobot
RD 06
by Rychiger
Specifications
- Weight
- 300 kg
- Frequency hz
- 50
- Size width (mm)
- 740
- Rated power kw
- 2
- Size height (mm)
- 1850
- Size length (mm)
- 500
- Cycle time max s
- 10
- Cycle time min s
- 5
- Connected load (v)
- 400
- Sealing time max s
- 180
- Sealing time min s
- 0.1
- Sealing force max n
- 6000
- Sealing force min n
- 500
- Compressed air flow l (min)
- 10
- Outer unit diameter max (mm)
- 120
- Sealing temperature max c
- 350
- Sealing temperature min c
- 50
- Compressed air pressure bar
- 4
Overview
The RD 06 is a compact tabletop machine for punching and sealing processes, designed for clean room operation (ISO class 7 and 8). It uses one stroke technology to seal and punch in a single cycle, with semi-automated operation via a touch panel HMI. Optional modules include foil handling and liquid filling. It is ideal for feasibility studies, small-series production, and format parts testing. The machine is servo driven, with a sealing force range of 500–6000 N and sealing temperature range of 50–350°C. It can be leased for small sample runs.
Key features
- ▸Compact tabletop machine, small footprint
- ▸One stroke technology for punching and sealing in a single process
- ▸Semi-automated operation with intuitive touch panel HMI
- ▸Two-hand control for operator safety
- ▸Optional foil handling module for roll stock
- ▸Preconfigured for liquid filling module installation
- ▸Suitable for ISO class 7 and 8 clean rooms
- ▸Sealing force 500–6000 N, sealing temperature 50–350°C
- ▸Cycle time 5–10 s, sealing time 0.1–180 s
- ▸Servo driven, connected load 3×400 V + Pe / 50 Hz
