Name: AGV-CDD16 Stacker Autonomous Forklift
Brand: Onewayrobot

AGV-CDD16 Stacker Autonomous Forklift Full page →Heavy logistics

The AGV-CDD16 is a laser SLAM stacker autonomous forklift with 1.6 T rated load capacity and 3 m lifting height. It uses SLAM navigation with ±10 mm accuracy, runs at 2 m/s, and recognizes various pallet types. Equipped with 360° obstacle detection, lithium iron phosphate battery (24 V/173 Ah, 8–10 h runtime), and automatic/manual charging. Designed for easy maintenance and flexible deployment.

•SLAM navigation with ±10 mm accuracy, no reflectors needed
•Maximum running speed 2 m/s in both no-load and full-load
•Lifting height 3 m with stable load capacity of 1.6 T
•Pallet recognition for international, European, and non-standard pallets
•360° obstacle detection with laser, 3D camera, bumper strip, distance sensor
•Lithium iron phosphate battery, 24 V / 173 Ah, 8–10 h runtime
•Automatic and manual charging, 2 h charge (10% to 80%)
•Family-based industrial design for easy disassembly and maintenance

Gap (mm)	15
Step (mm)	5
Depth	1925 mm
Speed	2 m/s
Width	1000 mm
Height	2040 mm
Length	1925 mm
Weight	1090 kg
Payload	1600 kg
Fork width (mm)	185
Fork height (mm)	55
Fork length (mm)	1220
Lift height (mm)	3000
Slope percent	5
Charge time	2 h
Battery life (hrs)	10
Ambient temp max c	50
Ambient temp min c	0
Battery voltage (v)	24
Fork outer width (mm)	685
Battery capacity ah	173
Min turning radius (mm)	1540
Load center distance (mm)	600
Braking distance1m per s (mm)	300
Ambient humidity max percent	90
Ambient humidity min percent	10
Braking distance1_5m per s (mm)	500
Navigation angle accuracy (deg)	0.5
Navigation position accuracy (mm)	10
Right angle aisle width pallet800x1200 (mm)	2430
Right angle aisle width pallet1000x1000 (mm)	2360
Right angle aisle width pallet1000x1200 (mm)	2450
