Outdoor
FIXAR 025
by FIXAR
Specifications
- Height ft
- 3.9
- Height
- 1200 mm
- Length
- 2400 mm
- Payload
- 10 kg
- Payload lb
- 22
- Wingspan m
- 2.9
- Wingspan ft
- 9.5
- Altitude max m
- 6115
- Altitude max ft
- 20062
- Flight time (min)
- 210
- Assembly time (min)
- 10
- Flight distance km
- 300
- Flight distance mi
- 186
- Max takeoff weight (kg)
- 24.9
- Max takeoff weight lb
- 54.9
Overview
FIXAR 025 is a fully electric VTOL UAV engineered for demanding missions. It offers up to 210 minutes flight time, 300 km flight distance, and up to 10 kg payload. With a wingspan of 2.9 m and body length 2.4 m, it operates at altitudes up to 6,115 m. Built with aviation-grade materials and proprietary software, it delivers autonomous mission execution including takeoff, landing, and real-time surface track-and-follow.
Key features
- ▸Fully electric VTOL UAV with up to 210 min flight time
- ▸Up to 300 km flight distance
- ▸Up to 10 kg payload capacity
- ▸Maximum takeoff weight 24.9 kg
- ▸Wingspan 2.9 m, body length 2.4 m, height 1.2 m
- ▸Operates at altitudes up to 6,115 m above sea level
- ▸92% of body generates lift, payload up to 40% of MTOW
- ▸Autonomous mission execution including takeoff, landing, and surface track-and-follow
- ▸Performs reliably in GNSS-denied zones
- ▸Fits in two transport cases, assembled in 10 minutes
